CM2 Series Stainless Steel Mini Cylinder (Single Acting)

CM2 Series Stainless Steel Mini Cylinder (Single Acting) is a stainless steel mini cylinder with a sophisticated design. It adopts the single-acting driving principle and is particularly suitable for space-constrained and clean corrosion-resistant environments. Its core relies on the on-off of the driving medium and the built-in spring to achieve directional movement and automatic reset of the piston rod.

·The piston rod extends when driving, and the spring resets when the pressure is removed: When the driving medium acts on the cylinder, it overcomes the built-in spring force and pushes the piston rod outward to do work; once the driving medium is removed or interrupted, the compressed spring immediately releases the stored energy, forcing the piston rod to retract stably and reliably to the initial position.
·The piston rod contracts when driving, and the spring extends when the pressure is removed: When the driving medium acts on the cylinder, it compresses the built-in spring and pulls the piston rod inward at the same time; after the driving medium is removed or interrupted, the reset force of the spring dominates, actively pushing the piston rod outward and returning to the original extended state.
